Description
|
Touch recognition mode |
Built-in infrared optical touch recognition( Support simultaneous 10 point continuous input |
||
|
Effective identification range |
Finger, stylus or other non-transparent object with diameter not less than 5mm (8mm for multiple points) |
||
|
Positioning accuracy |
±2mm More than 90% of the touch area |
||
|
response time |
8mm( The cursor speed is about 120 points /s) |
||
|
Touch resolution |
H：32767 V：32767 |
||
|
Touch life |
≥80 thousand hours |
||
|
PCB hardware configuration parameters |
|||
|
Main chip model |
TSUMV56RUU-Z1 |
||
|
RAM |
Built-in main chip |
||
|
Flash |
32 MB |
||
|
External extended storage |
USB2.0 interface supports up to 256GB |
||
|
PC module hardware configuration parameters |
|||
|
Configuration |
Standerd |
Professional |
|
|
CPU |
Intel Core i3 |
Intel Core i5 |
|
|
Chipset |
NM76-2310 / H81-4130 |
NM70-2450 / H81-4460 |
|
|
RAM |
4G DDR3 |
||
|
Built-in storage |
Standard 120GB SSD (optional 500GB mechanical hard disk *) |
||
|
GPU |
Graphics Intel Core HD Graphics |
||
|
The PC module Interface configuration
|
Default type |
||
|
1) USB2.0 x2 2) USB3.0 x2 3) RJ45 x1 4) HDMI (1.4a) x1 5) MIC x1 6) AUDIO LINE x1 7) VGA x1 8) Wi-Fi x1(support IEEE 802.11b/g/n) 9) Power start switch 10) One-key restore switch |
|||
